SCS12 Enceinte Overhead

Description

2-Way Coaxial with 12" LFThe SCS 12 is a coaxial-driver, 2-way, fullrange cinema surround loudspeaker ideal for multi-channel surround formats and is designed for overhead installation as well as for standard on-wall installations.FEATURES- 400 Watt power handling (average continuous pink noise) with high sensitivity provides high SPL capability.- Consistent 100° x 100° broadband pattern control- Extraordinary clarity cinema surround with extended frequency response for special effects- Components:• 300 mm (12 in) woofer with Kevlar reinforced cone and 75 mm (3 in) voice coil.

• 25 mm (1 in) exit compression driver with unique patented design and high temperature polymer diaphragm.- High-Power passive crossover network- Overload protectionSPECIFICATIONS- Frequency Range: (-10 dB) 55 Hz – 20 kHz- Frequency Response: (±3 dB) 70 Hz – 20 kHz- Coverage Pattern: 100° x 100°- Directivity Factor: (Q) 10.1 (1 k – 16 kHz)- Directivity Index: (DI) 9.

5 dB (1k – 16 kHz)- Long-Term System Power Rating (IEC) 400 W (1600 W peak), 2 hrs.- 250 W (1000 W peak), 100 hrs- Sensitivity (2.83V @ 1m) 96 dB (Ave.

70 Hz – 20 kHz)- Maximum SPL 122 dB (peaks of 128 dB) @ 1m- Crossover Network 1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF- Nominal Impedance: 8 ohms- Low Frequency Driver Kevlar-reinforced cone, 75 mm (3 in) voice coil.- High Frequency Driver 25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, patented design, fluidcooling.

- HF Driver Protection Minimum audibility SonicGuard™ HFoverload protection- Enclosure ABS with Glass enclosure, heavily braced- Attachment Two M10 points for included U-bracket.M6 secondary safety attachment point onback panel.- Grille Corrosion-resistant zinc-rich steel grille.

- Dimensions 402 x 402 x 445 mm (15.8 x 15.8 x 17.

5 in), cabinet 470 mm (18.5 in) depth with gland nut 502 mm (19.75 in) including bracket extending to back- Colors Black- Net Weight 14.

0 kg (31.0 lb), 16.8 kg (37.

0 lb) with U-Bracket- Shipping Weight 19.5 kg (43.0 lb)- Included Accessories U-bracket, Steel
